Anritsu
Anritsu Wireless Connectivity Test Set (WLAN Tester) MT8862A
Ideal for measuring the RF TRx characteristics at design and manufacturing inspection of WLAN devices, supporting IEEE 802.11a/b/g/n/ac/ax/be.
Ideal for measuring the RF TRx characteristics at design and manufacturing inspection of WLAN devices, supporting IEEE 802.11a/b/g/n/ac/ax/be. The Wireless Connectivity Test Set MT8862A (WLAN Tester) is for measuring the RF TRx characteristics of WLAN IEEE 802.11a/b/g/n/ac/ax/be (2.4 GHz, 5 GHz and 6 GHz bands) devices. The MT8862A has standard WLAN protocol messages (WLAN Signalling) to connect with the device under test (DUT) for measuring each TRx performance item as Network Mode, and features built-in Direct Mode to support flexible test environment.
Spesifikasi
| WLAN Standards | IEEE 802.11a/b/g/n/ac/ax/be |
|---|---|
| Frequency Bands | 2.4 GHz, 5 GHz and 6 GHz |
| Measurement Modes | Network Mode and Direct Mode |
| MIMO | 2x2 MIMO measurement functions |
| Measurements | Tx power, modulation accuracy (EVM), Rx sensitivity and packet error rate (PER) |
Butuh konsultasi teknis?
Kirim kebutuhan pengujian Anda — tim Terastek membantu menentukan konfigurasi yang sesuai.
