CONTEC DO-32L-PE — Digital output PCI Express card 32ch (isolated 12 - 24VDC)

This product is a PCI Express bus-compliant interface board for output of digital signals. This product can output digital signals at 12 – 24VDC. DO-32L-PE features 32 opto-coupler isolated open-collector outputs (current sink type). In addition, output transistor protection circuit (surge voltage protection and overcurrent protection). Windows/Linux device driver is supported with this product.

Key Features

• Standard Warranty 3 yrs
• Extended Warranty Available
• Opto-coupler isolated input (supporting current sink output) and opto-coupler isolated open-collector output (current sink type)
• Opto-coupler bus isolation
• You can use all of the input signals as interrupt events.
• Windows/Linux support device driver
• This product has a digital filter to prevent input signals from carrying noise or a chattering.
• Output circuits include zener diodes for surge voltage protection and overcurrent protection circuit.
