CONTEC F&eIT™ Remote I/O Systems Migration Guide
As an advanced remote I/O system with reduced wiring, the F&eIT™ Series I/O Controller Units have been long supported and appreciated.
As an advanced remote I/O system with reduced wiring, the F&eIT™ Series I/O Controller Units have been long supported and appreciated. However, we will be discontinuing sales and support for this series as of December 2025. Going forward, we encourage you to transition to the CONPROSYS™ nano Series, which offers superior cost performance and enhanced functionality.
Spesifikasi
| F&eIT | CONPROSYS nano |
|---|---|
| CPU-CA20(FIT)GY Coupler Module 1x LAN Up to 8 I/O modules | CPSN-MCB271-S1-041 Coupler Unit 1x LAN 4× I/O module slots |
| ADI12-8(FIT)GY Analog Input 12bit 8ch Screwless terminal block | CPSN-AI-1208LI Analog Input 12bit 8ch Screwless terminal block |
| ADI16-4(FIT)GY Analog Input 16bit 4ch Screw terminal block | CPSN-AI-1604LI Analog Input 16bit 4ch Screwless terminal block |
| DAI12-4(FIT)GY Analog Output 12bit 4ch Screwless terminal block | CPSN-AO-1204LI Analog Output 12bit 4ch Screwless terminal block |
| DAI16-4(FIT)GY Analog Output 16bit 4ch Screw terminal block | x2 | CPSN-AO-1602LC Analog Output 16bit 2ch Screwless terminal block * For 4ch, you need 2. |
| DIO-8/8(FIT)GY Digital I/O Input 8ch / Output 8ch Screwless terminal block | CPSN-DI-08L Digital Input 8ch Screwless terminal block |
| DIO-16/16(FIT)GY Digital I/O Input 16ch / Output 16ch Screwless terminal block | CPSN-DI-16BCL Digital Input 16ch 20pin MIL connector |
| x2 | CPSN-DI-08L Digital Input 8ch Screwless terminal block * For 16ch, you need 2. |
| x2 | CPSN-DO-08L Digital Output 8ch Screwless terminal block * For 16ch, you need 2. |
| DI-16(FIT)GY Digital Input 16ch Screwless terminal block | CPSN-DI-16BCL Digital Input 16ch 20pin MIL connector |
| DI-32(FIT)GY Digital Input 32ch Screwless terminal block | x2 | CPSN-DI-16BCL Digital Input 16ch 20pin MIL connector * For 32ch, you need 2. |
| x4 | CPSN-DI-08L Digital Input 8ch Screwless terminal block * For 32ch, you need 4. |
| DO-16(FIT)GY Digital Output 16ch Screwless terminal block | CPSN-DO-16L Digital Output 16ch 20pin MIL connector |
| DO-32(FIT)GY Digital Output 32ch Screwless terminal block | x2 | CPSN-DO-16L Digital Output 16ch 20pin MIL connector * For 32ch, you need 2. |
| x4 | CPSN-DO-08L Digital Output 8ch Screwless terminal block * For 32ch, you need 4. |
| RRY-4(FIT)GY Relay Output 4ch Screw terminal block | CPSN-RRY-4PCA Relay Output 4ch Screwless terminal block |
| CNT16-8(FIT)GY Up Counter 16bit 8ch Screw terminal block | CPSN-DI-16BCL Digital Input 16ch(shared with the counter) with counter function 32bit 2.5kHz(Up Counter) 20pin MIL connector |
| CNT24-2(FIT)GY Up-Down Counter 24bit 2ch Screwless terminal block | x2 | CPSN-CNT-3201I Up-Down Counter 32bit 1ch Screwless terminal block * For 2ch, you need 2. |
| Windows API-CAP(W32) Online help Linux API-CAP(LNX) Online help Dedicated driver for the F&eIT I/O controller unit. Contains APIs for digital I/O, analog I/O, counter, and other functions. | Windows Analog I/O API-AIO(WDM) Online help Digital I/O API-DIO(WDM) Online help Counter API-CNT(WDM) Online help Linux Analog I/O API-AIO(LNX) Online help Digital I/O API-DIO(LNX) Online help Counter API-CNT(LNX) Online help In CONPROSYS nano, drivers are provided for digital I/O, analog I/O, counter, and other functions. Install the driver for the required function. Many API functions such as basic instructions are shared with API-CAP (W32). |
