CONTEC SMB-C39U01-LLVA — Industrial Motherboard / Mini-ITX / Celeron 3965U (Kaby Lake SoC) / DC Power Supply
This product is the Mini-ITX mother board with M.2 slot.
This product is the Mini-ITX mother board with M.2 slot. It adopts Seventh-generation Intel® Core i7/i5/Celeron Processor and DDR4 SDRAM memory with up to 32GB can be equipped. In addition, a variety of interface such as dual-LAN, USB3.0, Displayport, DVI-D, and RS-232C are provided. Embedded-type CPU have been adopted. The use of readily available parts ensures the ease of the use of the product. In addition, the use of Contec-customized BIOS allows support to be provided at the BIOS level.
Key Features
- Standard Warranty 1 yr
- End of Repair Service: 2032/06/30
- Seventh-generation Kabylake-U processor adopted
- M.2 slot realizes high-speed data transfer
- Fan-less design reduces maintenance work
- A wide range of power supplies (10.8 to 31.2VDC) supported
- Major types of peripherals are supported with rich interfaces
Spesifikasi
| Type | Mini-ITX |
|---|---|
| Supported OS | Windows 10 |
| CPU Generation (Development code) | 7th Gen. (Kaby Lake-U) |
| Processor | Celeron 3965U |
| CPU socket | - |
| Memory | up to 32GB; 8GB |
| RAS | Hardware monitor (Temperature / Voltage); Remote power-on; Watchdog timer |
| GPU | - |
| AI Performance | - |
| Security | - |
| Video | 1x DisplayPort; 1x DVI-D |
| LAN | 2x 1000BASE-T |
| Wireless | - |
| Audio | 1x Line out; 1x Line in; 1x Mic-in |
| I/O | 4x USB3.2 Gen1 (USB3.0); 2x USB2.0; 1x RS-232C |
| Memory card | - |
| Video | - |
| LAN | - |
| Audio | 1x Front audio (1xpin header connector) |
| I/O | 2x USB2.0; 2x RS-232C |
| Power connector | - |
| Expansion bus | 1x M.2 Key M (2242); 1x PCI Express(x4) |
| Drive bay | - |
| Input voltage | 12 to 24VDC |
| Operating temperature | 0 to 60°C (32 to 140°F), during forced air cooling (0.5m/s); 0 to 55°C (32 to 131°F), during natural air cooling; 0 to 45°C (32 to 113°F), during natural air cooling |
| Storage temperature | -10 to 60°C (14 to 140°F) |
| Standards & Certifications | CE; FCC Class A; UKCA; VCCI Class A |
