CONTEC VPC-720 — Industrial Computer VPC-720 - Ultra Small / 13th Gen. Intel® Core™ Processor (Raptor Lake)

This product is a high-performance embedded-type personal computer equipped with the 13th-generation Intel® Core™ processor.

CONTEC VPC-720 — industrial computer, DAQ, IoT, or communication hardware

This product is a high-performance embedded-type personal computer equipped with the 13th-generation Intel® Core™ processor. It has extension interfaces such as HDMI, DisplayPort, 2.5GBASE-T, 1.0GBASE-T, USB 3.2 Gen1 (USB 3.0), serial and Audio. These Units are ideal for a wide range of embedded applications, such as control devices and information terminals based on general-purpose PC OSes. Embedded-type chipset and CPU have been adopted. The use of readily available parts ensures the ease of the use of the product.

Key Features

  • Standard Warranty 3 yr
  • Extended Warranty Available
  • Supports Intel® Core™ Processor Series Raptor Lake
  • Compact size that can be installed in a small space
  • Adopts removable storage structure
  • Supports mirroring (RAID1)
  • Abundant interfaces for freely expanding peripheral devices
  • Compatible with Trellix white listing anti-virus software

Spesifikasi

MountingDesktop
Supported OSWindows 11 IoT Enterprise LTSC 2024; Windows 10 IoT Enterprise 2021 LTSC 64-bit
CPU Generation (Development code)13th Gen. (Raptor Lake-S); 12th Gen. (Alder Lake-S)
ProcessorCore i7-13700TE; Core i5-13500TE; Core i3-13100TE; Celeron G6900TE
CPU socket-
Memoryup to 32GB
RASHardware monitor (Fan speed / Temperature / Voltage); Remote power-on
GPU-
AI Performance-
SecurityTCG TPM 2.0
Video2x DisplayPort; 1x HDMI
LAN1x 2500BASE-T/1000BASE-T/100BASE-TX/10BASE-T; 1x 1000BASE-T/100BASE-TX/10BASE-T
Wireless-
Audio1x Line out; 1x Mic-in
I/O6x USB3.2 Gen1 (USB3.0); 2x USB2.0; 2x RS-232C/422A/485
Memory card-
Expansion bus1x PCI Express(x16)
Drive bay2x 2.5-inch bay (SATA)
Input voltage100 to 240VAC
Operating temperature5 to 40°C (41 to 104°F)
Storage temperature-20 to 60°C (-4 to 140°F)
Standards & CertificationsCCC; CE; FCC Class A; UKCA; UL/cUL; VCCI Class A
