MCC 152: Voltage Output and DIO DAQ HAT for Raspberry Pi®

Measurement Computing Corporation (MCC) and Data Translation (DT) DAQ products are now part of the Digilent family of test and measurement solutions. MCC and DT are leading suppliers of data acquisition solutions that are easy-to-use, easy-to-integrate, and easy-to-support.
The MCC 152 Voltage Output and DIO HAT features two channels of analog voltage output and eight digital I/O for Raspberry Pi-based systems. The 12-bit voltage outputs feature a 0-5 V range and can be updated at up to 5 kS/s. Up to eight MCC HATs can be stacked onto one Raspberry Pi.
All DAQ HATs include C/C++® and Python™ examples and open-source library. Comprehensive API and hardware documentation are also provided.
There are five devices in the MCC DAQ HAT Series. Models are available with voltage inputs, thermocouple inputs, IEPE-based sensor inputs, analog outputs, and digital I/O allowing users to configure multifunction, Raspberry Pi-based data logger solutions.
Raspberry Pi is not included with the MCC 152.
OEM/Embedded Customers- please contact our dedicated application engineer for volume pricing and assistance with your application. Visit our OEM Board-only page for more product offerings.

The open-source MCC DAQ HAT Library of commands in C/C++ and Python allows users to develop applications on the Raspberry Pi using the Raspbian®/Raspberry Pi OS®. The library is available to download from GitHub. Comprehensive API and hardware documentation are available. The MCC DAQ HAT Library supports operation with multiple MCC DAQ HATs running concurrently. The library includes example programs developed in C/C++ and Python that users can run to become familiar with the DAQ HAT library and boards; source code is included.
DAQ HAT Library

Two 12-bit simultaneous voltage outputs
5 mA output drive, sourcing
0.8 V/µs slew rate
Eight bidirectional digital bits
5V / 3.3V operation; CMOS input thresholds
Programmable input polarity
Screw terminal connections

Product Compliance:

HTC: 8471809000
ECCN: EAR99

One MCC 152 DAQ HAT
2×20 Header connector (plugs into the 40 pin GPIO connector on the Pi board)
Jumpers (3)
Standoffs (4)
Screws (4)
Nuts (4)
Printed insert: Getting Started with MCC DAQ HATs
MCC packaging assembly/foam, etc.

Quickly find what you need to get started and reduce mean time to measure.
All product support including documentation, projects, and reference material can be accessed through MCC resources.
Digilent ForumMCC DAQ HAT Library Resources and Firmware UpdatesDAQ and Datalogging on Reference
Quick Links
MCC 152 Datasheet
