Pmod LVLSHFT: Logic Level Shifter

The Digilent Pmod LVLSHFT is a digital logic level shifter that uses the Texas Instruments SN47LVC1T45 transceiver. This module is ideal for users who want to supply logic signals following a 3.3V CMOS standard but have an alternate logic level output that is used for other applications, such as JTAG programming.
To view our EMC Disclaimer, click here.

Digital logic level shifter
Translate logic signals between two user supplied voltage levels
2×7 JTAG header
8 miniature switches to dictate logic level conversion
Voltage range between 1.8V and 5.5V
Small PCB size for flexible designs 1.8 in × 0.8 in (4.6 cm × 2.0 cm)
12-pin Pmod connector with GPIO interface

Pmod LVLSHFT
Custom antistatic Pmod packaging
