PCB Piezotronics 070 Coaxial & Connector Adaptor Series
PCB Piezotronics 070 is supplied as factory-terminated assemblies rather than as a single part; the 11 catalogue entries below cover the connector and length combinations PCB lists for this series. Each model number encodes the end connectors and the length.
Available models include 070A02, 070A03, 070A08, 070A109, 070A11, 070A12, 070A20, 070A43, 070A54, 070A95, 070B09.
Key Features
PCB Piezotronics 070 Coaxial & Connector Adaptor Series
- 11 catalogue variants
- Factory-terminated assemblies
- Variants identified by connector combination and length
Model & Varian
| Model | Description |
|---|---|
| 070A02 | Scope Input Adaptor 10-32 Jack-BNC Plug |
| 070A03 | Conn Adapt, Micro 10-32 Plug To BNC Jack |
| 070A08 | Cable Adapt Micro 10-32 Jack To BNC Jack |
| 070A109 | Coaxial Coupler, 10-32 Jk To 10-32 Jk |
| 070A11 | BNC "T" Conn, 2 BNC Jacks, 1 BNC Plug |
| 070A12 | BNC Coupler BNC Jack To BNC Jack Panduit |
| 070A20 | Right Angle Adaptor |
| 070A43 | Rt Angle BNC Jack To BNC Plug Adaptor |
| 070A54 | Connector Adaptor M4 To BNC |
| 070A95 | SMA Plug To BNC Jack Adaptor |
| 070B09 | Solder Conn Adaptor 2 Wire |
Geser tabel ke samping untuk melihat semua spesifikasi →
Spesifikasi
| Series | 070 |
|---|---|
| Catalog Variants | 11 |
| Termination | Factory terminated |
