PCB Piezotronics 201b/211b Series Force Sensor
Model 201B01:ICP® quartz force ring, 10 lb comp., 500 mV/lb
Available models include 201B01, 201B02, 201B03, 201B04, 201B05, 211B.
Model 201B01:ICP® quartz force ring, 10 lb comp., 500 mV/lb
This series includes the official PCB Piezotronics models listed below.
Key Features
Model 201B01:ICP® quartz force ring, 10 lb comp., 500 mV/lb
- Measurement Range: 10 lb (0.0445 kN)
- Sensitivity: (±15%)500 mV/lb (112405 mV/kN)
- Low Frequency Response: (-5%)0.01 Hz
- Upper Frequency Limit: 90000 Hz
- Temperature Range: -65 to +250 °F (-54 to +121 °C)
Model & Varian
| Model | Sensitivity (±15 %) | Measurement Range (Compression) | Maximum Static Force (Compression) | Upper Frequency Limit | Non-Linearity | Temperature Range | Temperature Coefficient of Sensitivity | Output Polarity (Compression) |
|---|---|---|---|---|---|---|---|---|
| 201B01 | 500 mV/lb / 112405 mV/kN | 10 lb / 0.0445 kN | 60 lb / 0.267 kN | 90000 Hz / [4] | ≤1 % FS / [1] | -65 to +250 °F / -54 to +121 °C | ≤0.03 %/°F / ≤0.054 %/°C | Positive |
| 201B02 | 50 mV/lb / 11240 mV/kN | 100 lb / 0.4448 kN | 600 lb / 2.67 kN | 90000 Hz / [4] | ≤1 % FS / [1] | -65 to +250 °F / -54 to +121 °C | ≤0.03 %/°F / ≤0.054 %/°C | Positive |
| 201B03 | 10 mV/lb / 2248 mV/kN | 500 lb / 2.224 kN | 3000 lb / 13.34 kN | 90000 Hz / [4] | ≤1 % FS / [1] | -65 to +250 °F / -54 to +121 °C | ≤0.03 %/°F / ≤0.054 %/°C | Positive |
| 201B04 | 5 mV/lb / 1124 mV/kN | 1000 lb / 4.448 kN | 6000 lb / 26.69 kN | 90000 Hz / [4] | ≤1 % FS / [1] | -65 to +250 °F / -54 to +121 °C | ≤0.03 %/°F / ≤0.054 %/°C | Positive |
| 201B05 | 1 mV/lb / 224.8 mV/kN | 5000 lb / 22.24 kN | 8000 lb / 35.59 kN | 90000 Hz / [4] | ≤1 % FS / [1] | -65 to +250 °F / -54 to +121 °C | ≤0.03 %/°F / ≤0.054 %/°C | Positive |
| 211B | 18 pC/lb / 4047 pC/kN | ≤5000 lb / ≤22.24 kN | 8000 lb / 35.59 kN | 90000 Hz / [2] [3] | ≤1 % FS / [1] | -100 to +400 °F / -73 to +204 °C | ≤0.02 %/°F / ≤0.036 %/°C | Negative |
Geser tabel ke samping untuk melihat semua spesifikasi →
Spesifikasi
| Sensitivity (±15 %) | 500 mV/lb / 112405 mV/kN |
|---|---|
| Measurement Range (Compression) | 10 lb / 0.0445 kN |
| Maximum Static Force (Compression) | 60 lb / 0.267 kN |
| Broadband Resolution (1) | 0.0002 lb-rms / 0.0008896 N-rms / [2] |
| Low Frequency Response (-5 %) | 0.01 Hz / [3] |
| Upper Frequency Limit | 90000 Hz / [4] |
| Non-Linearity | ≤1 % FS / [1] |
| Temperature Range | -65 to +250 °F / -54 to +121 °C |
| Temperature Coefficient of Sensitivity | ≤0.03 %/°F / ≤0.054 %/°C |
| Discharge Time Constant (at room temp) | ≥50 sec |
| Excitation Voltage | 20 to 30 VDC |
| Constant Current Excitation | 2 to 20 mA |
| Output Impedance | ≤100 Ohm |
| Output Bias Voltage | 8 to 14 VDC |
| Output Polarity (Compression) | Positive |
| Preload | 60 lb / 0.267 kN |
