Model 682A14:DIN rail mount vibration transmitter (for use w/ICP sensor), 4-20 mA output for fixed 0-1 ips pk vibration, raw vibration output, fixed 3.5 Hz
Available models include 682A14, 682A15, 682C03.
Model 682A14:DIN rail mount vibration transmitter (for use w/ICP sensor), 4-20 mA output for fixed 0-1 ips pk vibration, raw vibration output, fixed 3.5 Hz
This series groups the official PCB Piezotronics variants listed below. Differences such as frequency, configuration, connector, range, or regional option are shown in the table.
Key Features
Model 682A14:DIN rail mount vibration transmitter (for use w/ICP sensor), 4-20 mA output for fixed 0-1 ips pk vibration, raw vibration output, fixed 3.5 Hz
- Output Signal: 4 to 20 mA
- DC Power: 23 to 25 VDC
Model & Varian
| Model | Official Variant Description | Channels | Input Signal (Vibration) | Output Signal (DC Vibration) | Frequency Range (-3 dB) (Velocity) | Output Range (DC Velocity) | Temperature Range (Operating) | Temperature Range (Storage) | Humidity Range (Non-Condensing) |
|---|---|---|---|---|---|---|---|---|---|
| 682A14 | 682A14 Icp 4-20 Ma Transmitter | 1 | ±100 mV/g / ±10.2 mV/(m/s²) / [4] | 4 to 20 mA / [3] | 210 to 600000 cpm / 3.5 to 10k Hz / [2] [5] [6] | 0 to 1.00 in/sec pk / 0 to 25.4 mm/s pk / [4] | -13 to 158 °F / -25 to 70 °C | -40 to 257 °F / -40 to 125 °C | 0 to 95 % |
| 682A15 | 682A15 Icp 4-20 Ma Transmitter | 1 | ±100 mV/g / ±10.2 mV/(m/s²) / [4] | 4 to 20 mA / [3] | 210 to 600000 cpm / 3.5 to 10k Hz / [2] [5] [6] | 0 to 1.00 in/sec rms / 0 to 25.4 mm/s rms / [4] | -13 to 158 °F / -25 to 70 °C | -40 to 257 °F / -40 to 125 °C | 0 to 95 % |
| 682C03 | 682C03 Icp 4-20 Ma Transmitter | 1 | ±100 mV/g / ±10.2 mV/(m/s²) / [8] | 4 to 20 mA / [4] | 210 to 600000 cpm / 3.5 to 10k Hz / [2] [10] [11] | 0 to 0.5 in/sec pk or rms / 0 to 12.7 mm/s pk or rms / [7] [8] [9] | -13 to 158 °F / -25 to 70 °C | -40 to 257 °F / -40 to 125 °C | 0 to 95 % |
Geser tabel ke samping untuk melihat semua spesifikasi →
Spesifikasi
| Channels | 1 |
|---|---|
| Input Signal (Vibration) | ±100 mV/g / ±10.2 mV/(m/s²) / [4] |
| Output Signal (DC Vibration) | 4 to 20 mA / [3] |
| Output Signal (AC Vibration) | 100 mV/g / 10.2 mV/(m/s²) / [1] |
| Frequency Range (-3 dB) (Velocity) | 210 to 600000 cpm / 3.5 to 10k Hz / [2] [5] [6] |
| Output Range (DC Velocity) | 0 to 1.00 in/sec pk / 0 to 25.4 mm/s pk / [4] |
| Temperature Range (Operating) | -13 to 158 °F / -25 to 70 °C |
| Temperature Range (Storage) | -40 to 257 °F / -40 to 125 °C |
| Humidity Range (Non-Condensing) | 0 to 95 % |
| Power Required | DC Power |
| DC Power | 23 to 25 VDC |
| DC Power (maximum) | 100 mA |
| Excitation Voltage (delivered to sensor) | 19 to 21 VDC |
| Constant Current Excitation (delivered to sensor) | 3 to 5 mA |
| Output Span (±5.0 %) (DC Vibration Current Output) | 16 mA |
