Anritsu
Anritsu Power Meter ML2439A
4 channel benchtop power meter with front panel multi-touch display and keypad ready to configure measurements, along with a 50 MHz test source output located on the front…
4 channel benchtop power meter with front panel multi-touch display and keypad ready to configure measurements, along with a 50 MHz test source output located on the front panel for easy calibration ML2439A is a four channel Power Meter which accepts input from Anritsu USB power sensors, processes and displays measurements simultaneously. The ML2439A Peak Power Meter supports the following USB power sensors MA244xxA – Peak Power Sensors
Spesifikasi
| Channels | 2 CH Standard, 4 CH with Option ML2439A-0004 |
|---|---|
| Frequency Range | 10 MHz to 50 GHz (sensor dependent) |
| Input level range | 60 dBm to +20 dBm (sensor dependent) |
| Dynamic Range | (dBm)(1)-50 to +20-70 to +20-60 to +20-40 to +20 |
| Automatic measurements | Pulse, statistical, and markers measurements |
| Display Format | Graph (power vs time or CCDF) and Text (Numeric display) |
| Remote Interface | GPIB, Ethernet |
| Weight | 4.8 lbs, 2.2 kg |
| Dimensions | (H x W x D) 3.5 x 8.3 x 11.2 (in), 89 x 211 x 284 (mm) |
Butuh konsultasi teknis?
Kirim kebutuhan pengujian Anda — tim Terastek membantu menentukan konfigurasi yang sesuai.
Produk Terkait
Referensi
https://www.anritsu.com/en-us/test-measurement/products/ml2439a
