CONTEC VPC-1800-G — Industrial Computer VPC-1800-G - Slim Tower PC / Intel 12＆13th Gen. (Alder Lake/ Raptor Lake) / 1x PCIe(x1), 2x PCI / 3x PCI

This product is a BTO industrial computer that is equipped with an 12th generation Intel® Celeron processor and 13th generation Intel® Core™ processor series. The Intel® Q670 chipset with DDR5 memory (16GB – 128GB) provides advanced computing and graphical performance. This product features a variety of interfaces such as one each port of DVI-I, HDMI, DisplayPort, four USB3.2 Gen2 (USB3.1) ports (rear:4), four USB3.2 Gen1 ports (front:2, rear:2), four serial ports (RS-232C/422A/485×1, RS-232C×3), two 2.5GBASE-T and one to two 1000BASE-T ports, which can be used in a wide range of embedded applications such as general-purpose PC OS- based controllers and information terminals. Two types of expansion slots are provided: PCI slots x 3, or PCI- Express 3.0(x1) slot x1 and PCI slots x 2

Key Features

• Standard Warranty 2 yr
• Extended Warranty Available
• Compatible with Intel® Core™ processor series Raptor Lake
• High-performance graphics with CPU embedded type
• Mirroring (RAID1) supported
• Removable storage adopted
• Rich variety of interfaces to expand your peripherals freely
• The selection of expansion slots from PCI-Express 3.0(x1) or PCI board
