Pmod ENC: Rotary Encoder

The Pmod ENC features a rotary-shaft encoder with an integral push-button to provide multiple types of outputs, such as a way for users to quickly switch between multiple choices shown on a screen or predefined motor speeds. The module also includes a sliding switch that is commonly used as an on/off output. An encoder is commonly used in freely rotating volume knobs to detect how many "clicks" a knob has been rotated.
To view our EMC Disclaimer, click here.

Rotary push-button shaft encoder
Adds multiple types of user input to host board or project
Additional static slide switch
Small PCB size for flexible designs 1.5 in × 0.8 in (3.8 cm × 2.0 cm)
6-pin Pmod connector with GPIO interface
Follows Digilent Pmod Interface Specification Type 1
Library and example code available in resource center

Pmod ENC
Custom antistatic Pmod packaging

Quickly find what you need to get started and reduce mean time to blink.
All product support including documentation, projects, and the Digilent Forum can be accessed through the product resource center.
Resource Center
Quick Links
Reference ManualSchematic
