PCB Piezotronics 057 4-Conductor, Twisted/Shielded, Fep Cable
PCB Piezotronics · Sensor Cable
4-conductor, shielded, high temperature FEP cable
Key Features
4-conductor, shielded, high temperature FEP cable
- Cable Style: Multi Conductor - Shielded
- Number of Conductors: 4
- Cable Jacket Material: PTFE
- Temperature Range: -85 to +392 °F (-65 to +200 °C)
- * *
- All specifications are at room temperature unless otherwise specified.
- * *
Spesifikasi
| Number of Conductors | 4 |
|---|---|
| Cable Style | Multi Conductor - Shielded |
| Cable Configuration | Twisted Bundle |
| Temperature Range | -85 to +392 °F / -65 to +200 °C |
| Capacitance (conductor to conductor @ 70 °F (21 °C)) | 24 pF/ft / 79 pF/m |
| Cable Jacket Diameter | 0.19 in / 4.83 mm / [1] |
| Cable Jacket Material | PTFE |
| Cable Jacket Color | Orange |
| Conductor Style | Stranded - 19 strands 32 AWG |
| Conductor Material | Tin Plated Copper |
| Conductor Diameter (22 AWG) | 0.030 in / 0.762 mm / [1] |
| Shield Type Over Bundle | Braid: 85% Minimum Coverage |
| Shield Material Over Bundle | Tin Plated Copper |
| Bend Radius (minimum) | 1.90 in / 48.26 mm |
| Weight | 0.52 oz/ft / 48.16 gm/m / [1] |
