PCB Piezotronics 112 Pressure Sensor Series
Wide Operating temperature range of -400 to +662F (-240 to + 350C) pressure probe, 5000 psi, 3 pC/psi, 0.218 in dia. SS diaphragm, accel.
Available models include 112A06, 112B05.
Wide Operating temperature range of -400 to +662F (-240 to + 350C) pressure probe, 5000 psi, 3 pC/psi, 0.218 in dia. SS diaphragm, accel. comp., 5-point cal ranges at 5kpsi, 500psi and 100psi UHT-12 Element
This series groups the official PCB Piezotronics variants listed below. Model differences such as sensitivity, range, connector, temperature rating, hazardous-area option, or microphone response are shown in the table.
Key Features
- Measurement Range: 5,000 psi (34,475 kPa)
- Sensing Element: UHT-12™
- Temperature Range: -400 to +662 °F (-240 to +350 °C)
- Electrical Connector: 10-32 Coaxial Jack
- Weight: 0.21 oz (6.0 gm)
- * *
Model & Varian
| Model | Official Variant Description | Measurement Range | Maximum Pressure (Total) | Resonant Frequency | Rise Time (Reflected) | Non-Linearity | Maximum Shock | Acceleration Sensitivity | Temperature Range (Operating) |
|---|---|---|---|---|---|---|---|---|---|
| 112A06 | 112A06 Pressure Sensor | 5,000 psi / 34,475 kPa | 15,000 psi / 103,421 kPa | ≥200 kHz | ≤2.0 µ sec | ≤1.0 % FS / [1] | 10000 g pk / 98000 m/s² pk | ≤0.01 psi/g / ≤0.007 kPa/(m/s²) | -400 to +662 °F / -240 to +350 °C |
| 112B05 | 112B05 Pressure Sensor | 5000 psi / 34475 kPa | 10000 psi / 68950 kPa | ≥200 kHz | ≤2.0 µ sec | ≤1.0 % FS / [1] | 10000 g pk / 98000 m/s² pk | 0.003 psi/g / 0.0021 kPa/(m/s²) / [2] | -400 to +500 °F / -240 to +260 °C |
Geser tabel ke samping untuk melihat semua spesifikasi →
Spesifikasi
| Sensitivity (15 %) | 2.8 pC/psi / 0.41 pC/kPa |
|---|---|
| Measurement Range | 5,000 psi / 34,475 kPa |
| Maximum Pressure (Total) | 15,000 psi / 103,421 kPa |
| Resonant Frequency | ≥200 kHz |
| Rise Time (Reflected) | ≤2.0 µ sec |
| Non-Linearity | ≤1.0 % FS / [1] |
| Maximum Shock | 10000 g pk / 98000 m/s² pk |
| Acceleration Sensitivity | ≤0.01 psi/g / ≤0.007 kPa/(m/s²) |
| Temperature Range (Operating) | -400 to +662 °F / -240 to +350 °C |
| Temperature Response | See Graph |
| Maximum Flash Temperature | 3000 °F / 1649 °C |
| Maximum Vibration | 5000 g pk / 49000 m/s² pk |
| Output Polarity (Positive Pressure) | Negative |
| Capacitance | 66 pF / [2] |
| Insulation Resistance (662°F) | ≥1000000000 Ohm |
| Insulation Resistance (Room Temp.) | ≥1.0 Tohm |
