PCB Piezotronics 422exxa Series In-Line Charge Converter
Model 422E65/A:In-line charge converter, 1 mV/pC, +/-5V output, -5% frequency 5 Hz, 10-32 jack conn., Rad Hard
Available models include 422E65/A, 422E66/A.
Model 422E65/A:In-line charge converter, 1 mV/pC, +/-5V output, -5% frequency 5 Hz, 10-32 jack conn., Rad Hard
This series includes the official PCB Piezotronics models listed below.
Key Features
Model 422E65/A:In-line charge converter, 1 mV/pC, +/-5V output, -5% frequency 5 Hz, 10-32 jack conn., Rad Hard
- Sensitivity: (±2%)1 mV/pC
- Output Voltage: ±5 V
- Temperature Range: -65 to +250 °F (-54 to +121 °C)
- Housing Material: Stainless Steel
Model & Varian
| Model | Sensitivity (±2 %) (Charge Conversion) | Input Range | Low Frequency Response (-5 %) | High Frequency Response (4 mA) | Non-Linearity | Temperature Range (Operating) | Radiation Exposure Limit (Integrated Neutron Flux) | Maximum Shock |
|---|---|---|---|---|---|---|---|---|
| 422E65/A | 1 mV/pC | ±5000 pC | 5 Hz / [3] | 35 kHz / [1] [2] | ≤1.0 % FS | -65 to +250 °F / -54 to +121 °C | ≤10000000000 N/cm² | 1000 g pk / 9810 m/s² pk |
| 422E66/A | 10 mV/pC | ±500 pC | 5 Hz / [3] | 90 kHz / [1] [2] | ≤1.0 % FS | -65 to +250 °F / -54 to +121 °C | ≤10000000000 N/cm² | 1000 g pk / 9810 m/s² pk |
Geser tabel ke samping untuk melihat semua spesifikasi →
Spesifikasi
| Sensitivity (±2 %) (Charge Conversion) | 1 mV/pC |
|---|---|
| Input Range | ±5000 pC |
| Low Frequency Response (-5 %) | 5 Hz / [3] |
| High Frequency Response (4 mA) | 35 kHz / [1] [2] |
| Non-Linearity | ≤1.0 % FS |
| Temperature Range (Operating) | -65 to +250 °F / -54 to +121 °C |
| Radiation Exposure Limit (Integrated Neutron Flux) | ≤10000000000 N/cm² |
| Maximum Shock | 1000 g pk / 9810 m/s² pk |
| Humidity Range | 100 % |
| Radiation Exposure Limit (Integrated Gamma Flux) | ≤1 Mrad |
| Excitation Voltage | +18 to 28 VDC |
| Constant Current Excitation | 2.2 to 20 mA |
| Output Voltage | ±5 V |
| Output Bias Voltage | 9 to 14.5 VDC |
| Broadband Electrical Noise (1 to 10000 Hz) | 7.0 µV / -103 dB / [1] |
