PCB Piezotronics EX686B01 Csa Approved Usb Switch
PCB Piezotronics · Vibration Switch
Model EX686B01:Intrinsically-safe USB programmable electronic vibration switch with 2-pin MIL-C-5015 connector
Key Features
Model EX686B01:Intrinsically-safe USB programmable electronic vibration switch with 2-pin MIL-C-5015 connector
- Relay: (Type)SPST, Form A or B MOSFET
- Power Required: 24 to 240 V DC/AC 50/60 Hz
- Electrical Connector: 2-Pin MIL-C-5015
Spesifikasi
| Alarm Threshold (±10 %) | 0.25 to 5 in/sec pk / 4.5 to 90 mm/s rms / [1] |
|---|---|
| Frequency Range (±3 dB) | 420 to 60 kcpm / 7 to 1000 Hz |
| Hysteresis (% < Alarm Threshold) | 3; 6; or 10 % / [1] |
| Residual Vibration Level (Reference) | Dependent or Independent / [1] |
| Residual Vibration Level (% Alarm Threshold) | 1 to 40 % / [1] |
| MAVT (Sets Alarm Threshold to 2X actual vibration) | Enabled or Disabled / [1] |
| Power On Delay (±1 sec) | 3 or 20 sec / [1] |
| Startup Delay (±1 sec or 1 min ) (Time) | 1 to 60 sec or 1 to 30 min / [1] |
| Startup Delay (x Alarm Threshold) | x2; x4; x8; Blocked / [1] |
| Startup Delay (Active) | Enabled or Disabled / [1] |
| Operational Delay (±1 sec) | 1 to 60 sec / [1] |
| Relay(Type) | SPST, Form A or B MOSFET |
| Relay(Latching) | Latching / Non-Latching / [1] |
| Relay(Contacts) | Normally Open / Closed / [1] |
| Temperature Range (Operating) | -40 to 185 °F / -40 to 85 °C |
