PCB Piezotronics Splice & Splitter Kits Triple / Quintuple / Sextuple
Splice and splitter kits that fan one sensor signal out to several connectors or pigtails, including shielded-ground versions. Each part is ordered by its PCB code; the table lists the 15 codes in this group. Codes run from JS to SL. These are the connector-side parts for PCB ICP sensor cables - the cable itself is a separate series item.
Available models include JS, JW, JX, JY, JZ, LA, LC, LD, LK, LY, NF, NN, NV, PG, SL.
Key Features
PCB Piezotronics Splice & Splitter Kits Triple / Quintuple / Sextuple
- 15 PCB connector codes
- Ordered by code
- Splice and splitter kits that fan one sensor signal out to several connectors or pigtails, including shielded-ground versions.
Model & Varian
| Model | Description |
|---|---|
| JS | Triple Splice, 4-Socket 1/4-28 |
| JW | Triple Splice, BNC Plug |
| JX | Triple Splice, BNC Jack |
| JY | Triple Splice, 10-32 Plug |
| JZ | Triple Splice, 10-32 Jack |
| LA | Triple Splice, 10-32 Plug |
| LC | Triple Splice, SMB Plug |
| LD | Triple Splice, SMB Jack |
| LK | Triple Splice, SMA Plug |
| LY | Triple Splice, 8-Pin Mini DIN |
| NF | Triple Splice, BNC Plug W/ Shield Gnd |
| NN | Triple Splice, Mini 8-Pin DIN |
| NV | Triple Splice, 10-32 Plug W/ Shield Gnd |
| PG | Quintuple Splice, BNC Plugs & Pigtails |
| SL | Sextuple Splice, BNC Plugs & Pigtails |
Geser tabel ke samping untuk melihat semua spesifikasi →
Spesifikasi
| Connector Family | Kit Splice & Splitter |
|---|---|
| Codes | 15 |
| Catalog Codes | JS, JW, JX, JY, JZ, LA, LC, LD, LK, LY, NF, NN, NV, PG, SL |
