Tektronix A622/A621 AC Current Clamp BNC 2 kA Peak | Probe Arus
The A621 clamp-on probe measures AC currents from 100 mA to 2000 A peak over 5 Hz to 50 kHz, and the A622 measures AC/DC currents from 50 mA to 100 A peak.
Available models include A622, A621.
The A600 Series current probes are specifically designed to support measurements with the TekMeter® or oscilloscope.
A621 2000 Amp AC Current probe/BNC. This industrial-style clamp-on probe has a BNC connector and can be used with a shrouded banana plug adapter so it can be used on digital multimeters, TekMeter, and oscilloscopes. The A621 can measure AC currents from 100 mA to 2000 A peak over a frequency range of 5 Hz to 50 kHz. It provides a 1 mV, 10 mV, or 100 mV output for each Amp measured.
A622 100 Amp AC DC Current probe/BNC. This “long nose” style clamp-on probe uses a Hall Effect current sensor to provide a voltage output to oscilloscopes. It has a BNC connector and can be used with a shrouded banana plug adapter so it can also be used on digital multimeters, TekMeter, and oscilloscopes. The A622 can measure AC/DC currents from 50 mA to 100 A peak over a frequency range of DC to 100 kHz. It provides 10 mV or 100 mV output for each Amp measured.
Key Features
- A621 – AC – 5 Hz to 50 kHz
- A621 – 100 mA to 2000 A peak
- A621 – For DMMs and oscilloscopes
- A621 – Clamp on
- A622 – AC/DC – 100 kHz
- A622 – 50 mA to 100 A peak
- A622 – For DMMs and oscilloscopes
Model & Varian
| Model | Maximum Current | Minimum Current | Bandwidth |
|---|---|---|---|
| A622 | DC: 100 AMax RMS: 71 APeak Current: 100 A | 50 mA | 100 kHz |
| A621 | RMS: 1000 APeak: 2000 A | 10 mA | 50 kHz |
Geser tabel ke samping untuk melihat semua spesifikasi →
Spesifikasi
| Model overview | |
|---|---|
| Frequency range | A621: 5 Hz to 50 kHz; A622: DC to 100 kHz |
| Maximum input current | A621: 2000 A peak; A622: 100 A peak |
| Output | A621: 1 mV/A, 10 mV/A, 100 mV/A; A622: 10 mV/A, 100 mV/A |
| Maximum conductor diameter | A621: 54 mm (2.13 in.); A622: 11.8 mm (0.46 in.) |
| Termination | A621: BNC; A622: BNC |
| Maximum bare-wire voltage | A621: 600 V (CAT III); A622: 600 V (CAT III) |
| Safety | A621: UL3111-2-032, CSA1010.2.032, EN61010-2-032, IEC61010-2-032; A622: UL3111-2-032, CSA1010.2.032, EN61010-2-032, IEC61010-2-032 |
Aplikasi
Motor drives
Inverters
Power supplies
Avionics
