Head Expander
Available models include 03ST-300M, 03ST-400M, 03ST-500M, 06ST-400M, 06ST-500M, 06ST-600M, 10ST-400M, 10ST-500M, 10ST-600M, 10ST-800M, 20ST-500M, 20ST-600M, 20ST-800M, 20ST-1000M, 30ST-500M, 30ST-600M, 30ST-800M, 30ST-1000M, 50ST-500M, 50ST-600M, 50ST-800M, 50ST-1000M, 50ST-1200M.
HE series
A head expander can be added to larger test parts to expand electro-dynamic shaker coils. Made from lighter magnesium or aluminum alloy, it offers better strength-toweight ratio and frequency response characteristics.
Features
- High-quaility aerospace class Material ；
- Usable frequnency range up to 2,000Hz ；
- Metirc and English units optional ；
- Magnesium or Aluminum optional ；
- Various insert mounting hole patterns available ；
- Corrosion resistant:non-machined parts are paintes； machined parts are coated with lubricant ；
- Customization for special requirements ；
Model & Varian
| Model | Compatible vibration generator | Table size (mm) | Thickness (mm) | Moving part mass (kg) | Maximum load (kg) | Usage frequency (Hz) |
|---|---|---|---|---|---|---|
| 03ST-300M | EDS-300 | 300×300 | twenty five | 8.5 | 100 | 2000 |
| 03ST-400M | EDS-300 | 400×400 | 11.5 | 150 | — | — |
| 03ST-500M | EDS-300 | 500×500 | 17 | 150 | — | — |
| 06ST-400M | EDS-600 | 400×400 | twenty five | 14 | 150 | 2000 |
| 06ST-500M | EDS-600 | 500×500 | 40 | 26.5 | 300 | — |
| 06ST-600M | EDS-600 | 600×600 | 35 | 300 | — | — |
| 10ST-400M | EDM-1000 | 400×400 | twenty five | 15 | 150 | 2000 |
| 10ST-500M | EDM-1000 | 500×500 | 40 | 28 | 300 | — |
| 10ST-600M | EDM-1000 | 600×600 | 38 | 300 | — | — |
| 10ST-800M | EDM-1000 | 800×800 | 57 | 400 | — | — |
| 20ST-500M | EDM-2000 | 500×500 | 40 | 29 | 300 | 2000 |
| 20ST-600M | EDM-2000 | 600×600 | 38 | 300 | — | — |
| 20ST-800M | EDM-2000 | 800×800 | 50 | 72 | 400 | — |
| 20ST-1000M | EDM-2000 | 1000×1000 | 107 | 500 | — | — |
| 30ST-500M | EDM-3200 | 500×500 | 40 | 29 | 300 | 2000 |
| 30ST-600M | EDM-3200 | 600×600 | 38 | 300 | — | — |
| 30ST-800M | EDM-3200 | 800×800 | 50 | 72 | 400 | — |
| 30ST-1000M | EDM-3200 | 1000×1000 | 107 | 500 | — | — |
| 50ST-500M | EDM-5000S | 500×500 | 40 | 38 | 300 | 2000 |
| 50ST-600M | EDM-5000S | 600×600 | 46 | 300 | — | — |
| 50ST-800M | EDM-5000S | 800×800 | 50 | 85 | 400 | — |
| 50ST-1000M | EDM-5000S | 1000×1000 | 120 | 500 | — | — |
| 50ST-1200M | EDM-5000S | 1200×1200 | 167 | 500 | — | — |
Geser tabel ke samping untuk melihat semua spesifikasi →
Spesifikasi
| Compatible vibration generator | EDS-300; EDS-600; EDM-1000; EDM-2000; EDM-3200; EDM-5000S |
|---|---|
| Table size (mm) | 300×300 to 1200×1200 |
| Thickness (mm) | twenty five; 11.5; 17; 40; 35; 38; 57; 50; 107; 46; 120; 167 |
| Moving part mass (kg) | 8.5 to 500 |
| Maximum load (kg) | 100 to 400 |
| Usage frequency (Hz) | 2,000 |
