Keithley 2200 Series — Multi-Channel DC Power Supply | Catu Daya DC
Series 2220 and 2230 Multi-Channel Programmable DC Power Supplies are ideal for testing a wide range of devices, circuit boards, modules, and products that require multiple…
Available models include 2231A-30-3, 2220-30-1, 2220G-30-1, 2230-30-1, 2230G-30-1.
Series 2220 and 2230 Multi-Channel Programmable DC Power Supplies are ideal for testing a wide range of devices, circuit boards, modules, and products that require multiple power sources cost-effectively. Series 2200 supplies provide two channels, each capable of outputting up to 30V and up to 1.5A. Series 2230 supplies include two 30V/1.5A channels plus a 6V channel with up to 5A output for powering digital circuits. The Model 2231A-30-3’s two channels can supply up to 30V at 3A each; the third channel can provide up to 5V at 3A. See all DC power supplies » Learn about bench power supply basics »
Features and Benefits
- All channels have isolated outputs — Allows providing power to circuits that are optically isolated or transformer-isolated from each other and have different reference points.
- All channels are independently controlled — Supports powering up a circuit with multiple voltage levels (such as a digital circuit) that must be turned on in a specified time sequence.
- All channels have remote sensing — Ensures that programmed voltage is accurately applied to the load.
- Two 30V channels can be combined either in seriesor in parallel — Allows doubling output voltage or current.
- Low noise, linear regulation — Ensures the level of power applied to the DUT’s load terminals is accurate.
- Voltage and current outputs for all channels are displayed simultaneously — Allows easy observation of each output state.
- Front panel numerical keypad entry — Simplifies fast, precise entry of output values.
- Store frequently used configurations in any of 30 setup memory locations — Saves times when repeating tests.
- Per-channel output timer — Turns off any output after a predetermined test time.
Model & Varian
| Model | Description | Number of Outputs | Maximum Voltage | Maximum Current | Connectivity |
|---|---|---|---|---|---|
| 2231A-30-3 | Manual Triple Channel DC PS | 3 | 30 V | 3 A | USB |
| 2220-30-1 | DUAL CHANNEL DC PS | 2 | 30 V | 1.5 A | USB |
| 2220G-30-1 | DUAL CHANNEL DC PS w GPIB | 2 | 30 V | 1.5 A | USB, GPIB |
| 2230-30-1 | PROGRAMMABLE TRIPLE CHANNEL DC POWER SUPPLY | 3 | 30 V | 5 A | USB |
| 2230G-30-1 | PROGRAMMABLE TRIPLE CHANNEL DC PS w GPIB | 3 | 30 V | 5 A | USB, GPIB |
Geser tabel ke samping untuk melihat semua spesifikasi →
Spesifikasi
| Model & Series | Series 2220/2230/2231 Multi-Channel Programmable DC Power Supplies |
|---|---|
| Description | Model-dependent — see Model & Varian |
| Number of Outputs | Model-dependent — see Model & Varian |
| Maximum Voltage | 30 V |
| Maximum Current | 1.5 A to 5 A (model-dependent) |
| Connectivity | Model-dependent — see Model & Varian |
