PCB Piezotronics 086E80 Impulse Hammer
PCB Piezotronics · Impact Hammer
Miniature Instrumented Impulse Hammer, 0 to 50 lbf
Key Features
Miniature Instrumented Impulse Hammer, 0 to 50 lbf
- Sensitivity: (±20%)100 mV/lbf (22.5 mV/N)
- Measurement Range: 50 lbf pk (222 N pk)
- Hammer Mass: 0.17 oz (4.8 gm)
- * *
Spesifikasi
| Sensitivity (±20 %) | 100 mV/lbf / 22.5 mV/N / [2] |
|---|---|
| Measurement Range | 50 lbf pk / 222 N pk |
| Resonant Frequency | ≥100 kHz |
| Non-Linearity | ≤1 % / [1] |
| Excitation Voltage | 20 to 30 VDC |
| Constant Current Excitation | 2 to 20 mA |
| Output Bias Voltage | 8 to 14 VDC |
| Discharge Time Constant | ≥100 sec / [1] |
| Sensing Element | Quartz |
| Sealing | Epoxy |
| Hammer Mass | 0.17 oz / 4.8 gm / [3] |
| Head Diameter | 0.25 in / 6.3 mm |
| Tip Diameter | 0.10 in / 2.5 mm |
| Hammer Length | 4.2 in / 107 mm / [3] |
| Electrical Connection Position | Side |
