PCB Piezotronics
PCB 1630/0xc/1631/0xc Series S-Type Load Cell, 50 Lb, 1/4-28
S-Type Load Cell, 50 lbf rated capacity, 150% of RO static overload protection, 2mV/V output, 1/4-28 UNF threads, integral 10 ft cable w/ open end, aluminum construction
Available models include 1630-03C, 1630-04C, 1630-06C, 1631-01C, 1631-03C, 1631-04C, 1631-06C.
S-Type Load Cell, 50 lbf rated capacity, 150% of RO static overload protection, 2mV/V output, 1/4-28 UNF threads, integral 10 ft cable w/ open end, aluminum construction
This series includes the official PCB Piezotronics models listed below.
Key Features
S-Type Load Cell, 50 lbf rated capacity, 150% of RO static overload protection, 2mV/V output, 1/4-28 UNF threads, integral 10 ft cable w/ open end, aluminum construction
- Measurement Range: 50 lb (222 N)
- Size - Height: 2.50 in (64 mm)
- Electrical Connector: 10 ft - Integrated Cable
- * *
Model & Varian
| Model | Measurement Range | Sensitivity (±10 %) | Non-Linearity | Hysteresis | Non-Repeatability | Creep (in 20 minutes) | Resonant Frequency | Overload Limit |
|---|---|---|---|---|---|---|---|---|
| 1630-03C | 50 lb / 222 N / [1] | 2 mV/V / [2] | ≤0.05 % FS | ≤0.03 % FS | ≤0.02 %RO | ≤0.08 % | 1.5 kHz | 75 lb / 333 N |
| 1630-04C | 100 lb / 445 N / [1] | 2 mV/V / [2] | ≤0.05 % FS | ≤0.03 % FS | ≤0.02 %RO | ≤0.08 % | 1.8 kHz | 150 lb / 667 N |
| 1630-06C | 250 lb / 1112 N / [1] | 2 mV/V / [2] | ≤0.05 % FS | ≤0.03 % FS | ≤0.02 %RO | ≤0.08 % | 2.2 kHz | 375 lb / 1668 N |
| 1631-01C | 500 lb / 2224 N / [1] | 2 mV/V / [2] | ≤0.05 % FS | ≤0.03 % FS | ≤0.02 %RO | ≤0.08 % | 2.2 kHz | 750 lb / 3336 N |
| 1631-03C | 1000 lb / 4448 N / [1] | 2 mV/V / [2] | ≤0.05 % FS | ≤0.03 % FS | ≤0.02 %RO | ≤0.08 % | 3.2 kHz | 1500 lb / 6672 N |
| 1631-04C | 2000 lb / 8896 N / [1] | 2 mV/V / [2] | ≤0.05 % FS | ≤0.03 % FS | ≤0.02 %RO | ≤0.08 % | 2.4 kHz | 3000 lb / 13.3 kN |
| 1631-06C | 5000 lb / 22.2 kN / [1] | 2 mV/V / [2] | ≤0.05 % FS | ≤0.03 % FS | ≤0.02 %RO | ≤0.08 % | 2.5 kHz | 7500 lb / 33.4 kN |
Geser tabel ke samping untuk melihat semua spesifikasi →
Spesifikasi
| Measurement Range | 50 lb / 222 N / [1] |
|---|---|
| Sensitivity (±10 %) | 2 mV/V / [2] |
| Non-Linearity | ≤0.05 % FS |
| Hysteresis | ≤0.03 % FS |
| Non-Repeatability | ≤0.02 %RO |
| Creep (in 20 minutes) | ≤0.08 % |
| Resonant Frequency | 1.5 kHz |
| Overload Limit | 75 lb / 333 N |
| Load Limit (Side Force, F X or F Y) | 5 lb / 25 N / [3] |
| Load Limit (Bending Moment, M X or M Y) | 10 in-lb / 1 Nm / [3] |
| Load Limit (Axial Torque, M Z) | 10 in-lb / 1 Nm / [3] |
| Temperature Range (Operating) | -65 to +200 °F / -54 to +93 °C |
| Temperature Range (Compensated) | +70 to +170 °F / +21 to +77 °C |
| Temperature Effect on Output (Maximum) | ±0.0008 %Reading/°F / ±0.0015 %Reading/°C / [4] |
| Temperature Effect on Zero Balance (Maximum) | ±0.0015 %FS/°F / ±0.027 %FS/°C / [4] |
| Bridge Resistance | 350 Ohm / [5] |
