PCB Piezotronics 176A33 Charge Output Pressure Sensor
PCB Piezotronics · Pressure Transducer
Single ended charge output pressure sensor with UHT-12™ element, 6.0 pC/psi, +1400 F with double isolated 10-32 jack connector
Key Features
Single ended charge output pressure sensor with UHT-12™ element, 6.0 pC/psi, +1400 F with double isolated 10-32 jack connector
- Measurement Range: 3000 psi (206.8 bar)
- Sensing Element: UHT-12™
- Temperature Range: -94 to 1400 °F (-70 to 760 °C)
- Electrical Connector: 10-32 Coaxial Jack (10-32 Coaxial Jack)
- Weight: 3.10 oz (88 gm)
- * *
Spesifikasi
| Sensitivity (+/-20 %) | 6 pC/psi / 87 pC/bar |
|---|---|
| Sensitivity (±20 %) | 6 pC/psi / 87 pC/bar |
| Measurement Range | 3000 psi / 206.8 bar |
| Maximum Pressure (Total) | 5200 psi / 358.5 bar |
| Resonant Frequency | ≥100 kHz |
| Transverse Resonance | >15 kHz |
| Frequency Response (±5 %) | 20 kHz / [1] [2] |
| Non-Linearity | ≤1 % FS / [3] |
| Maximum Shock (Axial) | 2000 g pk / 19600 m/s² pk / [6] |
| Acceleration Sensitivity | 0.0036 psi/g / .00025 bar/g / [5] |
| Temperature Range (Operating) | -94 to 1400 °F / -70 to 760 °C |
| Temperature Range (Connector) | -65 to 900 °F / -54 to 482 °C |
| Temperature Response | See Graph / [4] |
| Hazardous Area Approval | See Manual |
| Radiation Exposure Limit (Integrated Neutron Flux) | 1E10 N/cm² |
| Radiation Exposure Limit (Integrated Gamma Flux) | 1E8 rad |
