NI
PXI-4496, 24-bit, 204.8 kS/s, 16 Input, 2 Gain,TEDS,AC-Coupled
204.8 kS/s, 114 dB, 2 Gains, 0.5 Hz AC-Coupled, 16-Input PXI Sound and Vibration Module
The PXI-4496 is designed for high-channel-count sound and vibration applications. With 24-bit analog inputs and IEPE constant current signal conditioning, the PXI-4496 is ideal for making precision measurements with microphones, accelerometers, and other transducers that have very large dynamic ranges. The PXI-4496 delivers simultaneous sampling on all channels. In addition, the PXI-4496 includes
built-in antialiasing filters that automatically adjust to your sampling rate and software-selectable input gains up to 20 dB, and TEDS smart sensor support for error-free setup.
Common applications include noise, vibration, and harshness (NVH) analysis, large microphone arrays, and dynamic structural test.
Spesifikasi
| Part Number | 779748-01 |
|---|---|
| Bus Connection | PXI |
| Front Connection Type | InfiniBand (IB)(2)#SMB(1) |
| Simultaneous Sampling | Yes |
| Product Description | PXI-4496, 24-bit, 204.8 kS/s, 16 Input, 2 Gain,TEDS,AC-Coupled |
