NI
PXI-6236, Iso (4 ±20 mA In, 4 ±10 V Out, DIO TTL: 6 In, 4 Out)
4 AI (16-Bit, 250 kS/s), 4 AO, 6 DI, 4 DO, Bank-Isolated, PXI Multifunction I/O Module
The PXI-6236 is a bank-isolated DAQ device designed for current I/O. It offers analog I/O, digital input, digital output, two 32-bit counters, and digital triggering. The digital input and outputs are compatible with 5 V TTL/CMOS signals. It combines the safety and performance benefits of isolation with high-performance timing, amplification, and calibration technologies to offer accurate measurements and precise control.
The PXI-6236 is ideal for test, measurement, control, and design applications in environments with high voltages and electrical noise. You can use the PXI-6236 to read from encoders, flow meters, and proximity sensors as well as control valves, pumps, and relays.
Spesifikasi
| Part Number | 779622-01 |
|---|---|
| Maximum Number of Single-Ended Analog Input Channels | 0 |
| Analog Input Resolution | 16 bits |
| Simultaneous Sampling | No |
| Maximum Sample Rate | 250 kS/s |
| Number of Counters/Timers | 2 |
| Number of Analog Output Channels | 4 |
| Maximum Analog Update Rate | 500 kS/s |
| Bus Connector | PXI Hybrid |
| Number of Bidirectional Digital Channels | 0 |
| Electrical Signal Measured | Current |
| Analog Input FIFO Buffer Size | 4095 samples |
| Maximum Number of Differential Analog Input Channels | 4 |
| Reconfigurable | Yes |
| Bus Connection | PXI Hybrid |
| Front Connection Type | D-SUB(1) |
| Number of Digital Input Only Channels | 6 |
| Number of Digital Output Only Channels | 4 |
| Product Description | PXI-6236, Iso (4 ±20 mA In, 4 ±10 V Out, DIO TTL: 6 In, 4 Out) |
