NI PXIe-6251 (16 Analog Inputs, 24 Digital I/O, 2 Analog Outputs)
PXIe, 16 AI (16-Bit, 1.25 MS/s), 2 AO , 24 DIO, PXI Multifunction I/O Module
The PXIe-6251 offers analog I/O, correlated digital I/O, two 32-bit counters/timers, and analog and digital triggering. The device delivers low-cost, reliable DAQ capabilities in a wide range of applications from simple applications in laboratory automation, research, design verification/test, and manufacturing test. You can add sensor and high-voltage measurement capability to your device with SCC or SCXI signal conditioning modules. The included NI-DAQmx driver and configuration utility simplify configuration and measurements.
Spesifikasi
| Part Number | 779777-01 |
|---|---|
| Maximum Number of Single-Ended Analog Input Channels | 16 |
| Analog Input Resolution | 16 bits |
| Simultaneous Sampling | No |
| Maximum Sample Rate | 1.25 MS/s |
| Number of Counters/Timers | 2 |
| Number of Analog Output Channels | 2 |
| Maximum Analog Update Rate | 2.86 MS/s |
| Bus Connector | PXI Express |
| Number of Bidirectional Digital Channels | 24 |
| Electrical Signal Measured | Voltage |
| Maximum Number of Differential Analog Input Channels | 8 |
| Reconfigurable | Yes |
| Bus Connection | PXI Express |
| Digital I/O Logic Levels | 5 V TTL |
| Front Connection Type | VHDCI(1) |
| Analog Input Voltage Range | -0.1 V to 0.1 V; -0.2 V to 0.2 V; -0.5 V to 0.5 V; -1 V to 1 V; -2 V to 2 V; -5 V to 5 V; -10 V to 10 V |
| Number of Voltage Output Channels | 2 |
| Analog Output Resolution | 16 bits |
| Product Description | NI PXIe-6251 (16 Analog Inputs, 24 Digital I/O, 2 Analog Outputs) |
