Tektronix TBS1000C Series — Osiloskop Digital 2 Kanal
Tektronix TBS1000C Series · Osiloskop
Spesifikasi Utama
- BandwidthUp to 200 MHz
- Analog channels2
- Sampling Rate1 GS/s
- Warranty5 years
- Analog Bandwidth50 MHz
- Analog Channels2
Gambaran Umum
Osiloskop TBS1000C memberikan kualitas dan keandalan terbaik untuk institusi pendidikan, perancang embedded, dan pemilik usaha kecil. Dengan antarmuka yang intuitif, bantuan bawaan, dan garansi 5 tahun, osiloskop 2 kanal ini membantu Anda belajar dan berinovasi dengan percaya diri.
Spesifikasi
| Bandwidth | Up to 200 MHz |
| Analog channels | 2 |
| Sampling Rate | 1 GS/s |
| Warranty | 5 years |
| Analog Bandwidth | 50 MHz |
| Analog Channels | 2 |
| Sample Rate | 1 GS/s |
| Record Length | 20k points |
| Display | 7-inch WVGA color, 15 horizontal divisions |
| Automated Measurements | 32 |
| FFT | Dual window — simultaneous time and frequency domain |
| Education Features | HelpEverywhere, built-in courseware, disable AutoSet/Cursors/Measurements, Kensington lock |
| Audience | Standard |
Aplikasi
Tektronix Tektronix TBS1000C Series — aplikasi utama dari pabrikan:
Embedded Design
The TBS1000C digital storage oscilloscope provides the embedded design engineer with a 7-inch WVGA display that shows 50% more horizontal signal with 15 divisions.
- Easily and quickly pan and zoom to quickly see signal details in areas of interest
- 32 automatic measurements enable you to measure the most commonly needed parameters
- Built in FFT for quick frequency domain analysis
Education
The TBS1000C digital storage oscilloscope offers new features that enable educators to devote more time to teaching engineering concepts and less time on lab setup and management.
- Built-in Courseware Lab Viewer
- HelpEverywhere system with on-screen tips and hints throughout the user interface
- Ability to independently disable AutoSet, Cursors and Measurements
- Five-year warranty as standard
- Kensington lock
Model & Varian
Tektronix TBS1000C Series — pilih model yang sesuai, minta penawaran via WhatsApp.
| Model | Analog Bandwidth | Sample Rate | Record Length | Analog Channels | |
|---|---|---|---|---|---|
| TBS1052C-EDU | 50 MHz | 1 GS/s | 20k points | 2 | Tanya Harga |
| TBS1052C | 50 MHz | 1 GS/s | 20k points | 2 | Tanya Harga |
| TBS1072C | 70 MHz | 1 GS/s | 20k points | 2 | Tanya Harga |
| TBS1102C | 100 MHz | 1 GS/s | 20k points | 2 | Tanya Harga |
| TBS1202C | 200 MHz | 1 GS/s | 20k points | 2 | Tanya Harga |
