Keysight N5185A MXG Analog Signal Generator, 8.5 GHz | Generator Sinyal Analog MXG
MXG analog signal generator covering 9 kHz to 8.5 GHz, with an optional secondary DDS tone generator for reducing second harmonic tones.
Available models include N5183B, N5185A.
The N5185A is an MXG analog signal generator covering 9 kHz to 8.5 GHz.
Option CW1 adds a secondary DDS tone generator that can reduce the second harmonic tone for CW signals, with up to 15 dB nominal improvement.
Fitur Utama:
- Carrier frequency range of 9 kHz to 8.5 GHz
- Optional secondary DDS tone generator (Option CW1) for harmonic reduction
- Up to 15 dB nominal improvement in second harmonic tone
- Compatible with harmonic products of CW signals
Model & Varian
| Model | Type | Frequency range |
|---|---|---|
| N5183B | MXG analog (microwave) | 9 kHz to 13 / 20 / 31.8 / 40 GHz |
| N5185A | MXG analog | 9 kHz to 8.5 GHz |
Geser tabel ke samping untuk melihat semua spesifikasi →
Spesifikasi
| Carrier frequency range | 9 kHz to 8.5 GHz |
|---|---|
| Carrier amplitude range | +10 to -50 dBm (nominal) |
| Secondary DDS tone generator | Option CW1, reduces the second harmonic tone for CW signals |
| Secondary DDS frequency range | 9 kHz to 8.5 GHz |
| Secondary DDS amplitude range | -10 to -70 dBc (nominal) |
| Secondary DDS phase range | -180 to +180 degrees (nominal) |
| Maximum tone improvement | Up to 15 dB (nominal) |
| Instrument type | MXG analog signal generator |
| Series | Keysight MXG signal generator |
