Keysight E8663D PSG RF Analog Signal Generator, 9 GHz | Generator Sinyal RF Analog PSG
PSG RF analog signal generator covering 100 kHz to 9 GHz, with the phase noise and spectral purity of the PSG family in a lower-frequency model.
Available models include E8257D, E8663D.
The E8663D is the RF analog model of the Keysight PSG signal generators, covering 100 kHz to 9 GHz.
It brings PSG phase noise and spectral purity to RF applications, and shares the PSG command compatibility and memory structure.
Fitur Utama:
- Frequency range 100 kHz to 9 GHz
- PSG phase noise and spectral purity
- Fully synthesised analog signal generator
- Emulates commands for earlier Keysight signal generators
Model & Varian
| Model | Type | Frequency |
|---|---|---|
| E8257D | PSG microwave analog | 250 kHz to 13 GHz and above, option dependent |
| E8663D | PSG RF analog | 100 kHz to 9 GHz |
Geser tabel ke samping untuk melihat semua spesifikasi →
Spesifikasi
| Frequency range | 100 kHz to 9 GHz |
|---|---|
| Instrument type | Fully synthesised RF analog signal generator |
| Key characteristics | PSG phase noise and spectral purity |
| Compatibility | Emulates applicable commands for earlier Keysight signal generators |
| Series | Keysight PSG signal generator |
| Harmonics | -25 dBc typical below 1 MHz; -28 dBc from 10 to below 60 MHz; -45 dBc with Option 1EH filters |
| Spectral purity | Spurious and harmonic performance specified at +10 dBm or maximum specified output power, whichever is lower |
| Phase noise warranty conditions | Warranted from 15 to 35 degrees C, excluding external mechanical vibration |
