PXI-5153 PXI Oscilloscope, 500 MHz, 8 bits, 2 GS/s, 2 Channels, 256 MB/ch
The PXI-5153 high-speed PXI oscilloscope has two channels with flexible settings for coupling, voltage range, and filtering.
The PXI-5153 high-speed PXI oscilloscope has two channels with flexible settings for coupling, voltage range, and filtering. PXI oscilloscopes also feature a number of triggering modes, deep onboard memory, and an instrument driver that includes data streaming and analysis functions. This device is ideal for applications with fast signals that require up to 500 MHz of analog bandwidth and flexible measurement configurations. The PXI-5153 also features PXI synchronization and data streaming capabilities.
Model & Varian
| Model | Part Number | Oscilloscope Onboard Memory Size | Product Description |
|---|---|---|---|
| PXI-5153 | 780317-03 | 256 MB/ch | PXI-5153 PXI Oscilloscope, 500 MHz, 8 bits, 2 GS/s, 2 Channels, 256 MB/ch |
| PXI-5153 | 780317-01 | 8 MB/ch | PXI-5153 PXI Oscilloscope, 500 MHz, 8 bits, 2 GS/s, 2 Channels, 8 MB/ch |
| PXI-5153 | 780317-02 | 64 MB/ch | PXI-5153 PXI Oscilloscope, 500 MHz, 8 bits, 2 GS/s, 2 Channels, 64 MB/ch |
Geser tabel ke samping untuk melihat semua spesifikasi →
Spesifikasi
| Part Number | 780317-03 |
|---|---|
| Bus Connection | PXI Hybrid |
| Analog Input Impedance | 50 Ohm |
| Oscilloscope Maximum Bandwidth | 500 MHz |
| Number of Voltage Input Channels | 2 |
| Maximum Sample Rate | 2 GS/s |
| Analog Input Voltage Range | -2.5 V to 2.5 V |
| Oscilloscope Onboard Memory Size | 256 MB/ch |
| Analog Input Resolution | 8 bits |
| CableSense™ | No |
| Supported Hardware Platform | PXI |
| Reconfigurable | No |
| Supports Peer To Peer Streaming | No |
| Analog Input Coupling | AC/DC |
| Enclosed | Yes |
| Onboard Digital Downconverter | No |
| Product Description | PXI-5153 PXI Oscilloscope, 500 MHz, 8 bits, 2 GS/s, 2 Channels, 256 MB/ch |
