Siglent SDG1000X Waveform and Function Generator 25/30/60 MHz 2 Channels | Generator Fungsi/Bentuk Gelombang
The SDG1000X series has a frequency as high as 60MHz and a sampling rate of 150 MSa/s, which ensures accurate waveform reproduction.
Available models include SDG1032X, SDG1022X, SDG1062X.
The SDG1000X series has a frequency as high as 60MHz and a sampling rate of 150 MSa/s, which ensures accurate waveform reproduction. Users can also create complex waveform sequences through the sequence function to meet complex test requirements.
Key Features
- Dual-channel, with maximum 60 MHz Square and Sine wave output frequency
- 150 MSa/s Sampling rate, 14 bit vertical resolution
- TrueArb technology, Arbitrary wave length 2 ~ 16 kpts
- Pulse width and rise/fall time finely adjustable
- Complex signal synthesis
- 4.3” TFT-LCD display
Model & Varian
| Model | Max Output Frequency | Sampling Rate | Vertical Resolution | Waveform Length | Channels |
|---|---|---|---|---|---|
| SDG1032X | 30 MHz | 150 MSa/s | 14-bit | 16 kpts | 2 |
| SDG1022X | 25 MHz | 150 MSa/s | 14-bit | 16 kpts | 2 |
| SDG1062X | 60 MHz | 150 MSa/s | 14-bit | 16 kpts | 2 |
Geser tabel ke samping untuk melihat semua spesifikasi →
Spesifikasi
| Model Variants | SDG1032X, SDG1022X, SDG1062X |
|---|---|
| Max Output Frequency | 30 MHz; 25 MHz; 60 MHz |
| Sampling Rate | 150 MSa/s |
| Vertical Resolution | 14-bit |
| Waveform Length | 16 kpts |
| Channels | 2 |
